Newmar BX-3 Splashproof Aluminum Junction Box

Description

The Newmar BX-3 Junction Box provides a protected connection point for marine wiring in wheelhouses, below-deck spaces, and engine-room installations. Its rugged cast-aluminum enclosure is rated IP54 splashproof and helps shield terminal connections from accidental contact and environmental exposure.

The metal enclosure can also help reduce electrical interference around sensitive wiring. Multiple grommeted cable entries provide straightforward access, while the included connector strips secure conductors with compression fittings so separate crimp terminals are not required.

The BX-3 contains two connector strips with 11 positions per strip. Each position supports wire up to 14 AWG and up to 10A. Two cable entries accommodate approximately 0.59-inch diameter cable.

For marine wiring installations that need multiple protected low-current connections in a compact, splash-resistant metal enclosure, the Newmar BX-3 provides a clean junction point with compression-style terminals already installed. See our other wire connectors & terminals.
