Victron SmallBMS NG for Lithium NG Batteries

Description

The Victron SmallBMS NG is an all-in-one battery-management system for Victron Lithium NG batteries in installations that do not require VE.Bus inverter/charger integration. It provides essential lithium battery protection and coordinated control of charging sources and loads while keeping the system simpler than a full VE.Bus BMS NG installation.

The BMS monitors the connected Lithium NG battery system and manages load disconnect, charge disconnect, and pre-alarm functions. The Load Disconnect output can control compatible BatteryProtect units, inverters, DC-DC converters, and other equipment with remote on/off inputs to prevent damaging deep discharge. The Charge Disconnect output can control compatible chargers, Cyrix-Li relays, battery combiners, or BatteryProtect devices when charging must stop.

Built-in Bluetooth connects directly to the Lithium NG battery system for centralized monitoring through VictronConnect. Battery current and state-of-charge data are received directly from the batteries, so a separate SmartShunt is not required for basic battery monitoring. A pre-alarm output can drive a relay, LED, or buzzer before a low-voltage shutdown, while remote on/off allows external control of the charge and load disconnect outputs.

Lithium NG batteries can be configured in series, parallel, or series/parallel arrangements for 12V, 24V, and 48V systems. The architecture supports up to 50 batteries in 12V or 24V banks and up to 25 batteries in 48V banks.

For Lithium NG systems that need battery protection, Bluetooth monitoring, and control of chargers and loads without integrating a VE.Bus inverter/charger, the SmallBMS NG provides a streamlined management solution. Have a look at the rest of our battery management systems.
