Veratron Pyrometer Sensor 900C 1650F LinkUp

Description

This Veratron Pyrometer Sensor, 100-900°C/250-1650°F, pairs with a LinkUp Gateway Module to bring wide-range temperature monitoring to a network, covering exhaust, engine coolant, raw water, intake air, engine oil, transmission fluid, or fuel, depending on where the sensor actually gets installed.

Installation and configuration are plug-and-play once paired with the LinkUp system, and the sensor is NMEA 2000 certified for reliable integration into an existing network. A thermocouple element handles the actual sensing, transmitting an analog signal over a LIN bus connection back to the LinkUp gateway.

LIN bus signal, 6-24VDC operating voltage, 0-37mV thermocouple signal output, ring tongue connector, R1/4″ male thread, adjustable sender length up to 60mm, 6mm sensor diameter, 20 Nm torque. Sold individually.

See the rest of our marine gauges.

• 100-900°C/250-1650°F measurement range
• Thermocouple sensing element
• Works with exhaust gas, coolant, water, air, oil, transmission fluid, or fuel
• NMEA 2000 certified via LinkUp pairing
