Trident 20-Foot High-Pressure LPG Supply Hose

Description

The Trident 20-foot high-pressure LPG supply hose is a fully assembled line for routing high-pressure propane between compatible components in an LPG system. Its long length provides flexibility when cylinders, regulators, or other approved system components must be separated by a substantial distance within a properly designed installation.

Solid brass 3/8-inch female swivel-flare fittings are installed on both ends, allowing the hose to connect without twisting the hose body during final tightening. The high-pressure LPG hose is designed to resist corrosion and avoid the stress and fatigue cracking associated with rigid metallic tubing in applications where flexible routing is appropriate.

The hose is UL Listed and factory leak-tested, but the completed LPG system still requires proper installation and leak testing at every connection. Route the hose away from heat, abrasion, sharp edges, and moving equipment, support it appropriately, and use only with compatible LPG fittings and system components that match the intended pressure service.

• The 20-foot hose provides flexible reach between compatible high-pressure system components.
• Female swivel-flare fittings on both ends simplify alignment during installation.
• Flexible LPG hose avoids several problems associated with rigid tubing in moving or vibration-prone environments.
• The hose is UL Listed and supplied fully assembled and leak-tested.
