Shakespeare 5401-XT Galaxy 4′ Antenna – 3dB Gain [5401-XT]

Sale!
Shakespeare 5401-XT Galaxy 4' Antenna - 3dB Gain [5401-XT]

Shakespeare 5401-XT Galaxy 4′ Antenna – 3dB Gain [5401-XT]

Original price was: $199.99.Current price is: $100.93.

SKU: CWR-14038 Category:

Description

5401-XT Galaxy 4′ Antenna

Center-fed 1/2 wave coaxial sleeve

This antenna is the same as the Style 5400-XT, but in an exclusive black Galaxy finish. It’s an outstanding, 4′ antenna of heavy-duty construction for general purpose communications. Its at home on T-tops, hard-tops and other positions aloft, where its small size can deliver maximum range.

Features:

  • Brass and copper elements for maximum range
  • Stainless steel ferrule with standard 1″-14 thread
  • Includes 20′ RG-8/X cable and a PL-259 connector
  • Suggested mount: Shakespeare Style 4187 Ratchet Mount
  • One section
  • Shakespeare Limited Warranty: 5 years
  • Includes FME Cables

Technical Specifications:

Frequency: VHF Marine Band
Bandwidth: 5 MHz within 2.0:1 VSWR
SWR: nominally 1.5:1 at 156.8 MHz
Gain: 3 dB
Max Input (Watts): 50 watts
Height (feet): 4

Specifications:

  • Antenna Band: VHF
  • Color: Black
  • Construction: Fiberglass
  • Ferrule Type: Stainless Steel
  • Length (Inches): 4′
  • Box Dimensions: 3″H x 3″W x 55″L WT: 3.1 lbs
  • UPC: 719441100612

Quick Guide (pdf)
