Scanstrut Flip Pro Duo USB-A USB-C 12V Socket

Description

The Scanstrut Flip Pro Duo combines USB-A charging, high-power USB-C charging, and a standard 12V power socket in one compact marine accessory module. It gives boat owners a single installation point for legacy USB devices, newer USB-C electronics, and conventional 12V accessories without filling the console with separate sockets.

The USB-C output supports fast charging up to 60W maximum on a 24V system, with supported output profiles up to 20V at 3A. On a 12V system, USB-C output supports 5V, 9V, and 12V profiles up to 3A. The USB-A port supports multiple output profiles up to 12V, making the unit useful for a broad range of phones, tablets, cameras, and other electronics.

The Flip Pro Duo accepts 10-32V DC input and draws up to 6A, with a 10A fuse recommended. The integrated 12V socket can support 120-150W maximum power on a 12V system. Installation uses a standard 32mm, approximately 1.25-inch, hole saw, keeping the cutout straightforward for new builds and refits.

Spring-loaded caps close tightly when the ports are not in use. With the covers closed, the assembly is IPX4 rated. A UV-resistant body plus a 316 stainless steel hinge and spring are designed for exposed marine use. Compliance includes CE, FCC, UKCA, C-Tick, and RoHS certifications. Have a look at the rest of our battery charging accessories.
