Raymarine RVX1000 3D Chirp Sonar Module – E70511

Description

Raymarine RVX1000 3D Chirp Sonar Module – E70511

The Raymarine RVX1000 3D CHIRP Sonar Module (E70511) is a high-performance “black box” sonar solution that brings the advanced imaging capabilities of the Axiom Pro series to a wider range of Raymarine displays. It is a versatile 5-channel sonar module designed for both inshore precision and offshore power.

Professional-Grade Sonar Performance

The RVX1000 is powered by a dedicated quad-core processor, allowing it to run multiple sonar channels simultaneously without any lag. It combines RealVision 3D technology with a high-powered 1kW CHIRP sonar, making it capable of identifying subtle underwater structures and tracking fish at extreme depths.

• 5-Channel Sonar: Includes RealVision 3D, CHIRP SideVision, CHIRP DownVision, low-power High-Frequency CHIRP, and high-power 1kW CHIRP.

• Extreme Depth Range: Capable of reaching depths up to 5,000 feet when paired with a compatible 1kW transducer.

• RealVision 3D Gyro Stabilization: Compensates for boat movement to deliver life-like, stable 3D imagery even in rough seas.

• Sonar Scroll Back: Allows you to rewind, pause, and playback up to 10 minutes of recorded sonar history to better identify targets and plot waypoints.

Technical Specifications

• Transducer Ports: Dual ports (1x 25-pin RealVision port and 1x 11-pin 1kW port).

• Compatibility: Works with all LightHouse 3 or 4 enabled MFDs (Axiom, Axiom Pro, eS Series, and gS Series).

• Imaging Specs: SideVision range of 300ft; DownVision range of 600ft; High-Frequency CHIRP range of 900ft.

• Waterproof Rating: Rugged IPX6/IPX7 construction for demanding marine environments.

• Included in Box: Sonar module, 1.5m power cable, 2m RayNet network cable, and mounting hardware.
