Bluewater 22mm Off/On/On Push Button Switch, 4-Ft Lead

Sale!
Bluewater 22mm Off/On/On Push Button Switch, 4-Ft Lead

Bluewater 22mm Off/On/On Push Button Switch, 4-Ft Lead

Original price was: $59.20.Current price is: $45.46.

Category:

Description

The Bluewater 22mm Off/On/On Push Button Switch provides three-position control in a compact stainless-steel format for marine dashboards and panels. Its standard Off-On-On contact supports applications that need two selectable powered states from one push-button control.

The LED ring is blue when off, green at the first ON position, and red at the second ON position, giving operators clear visual confirmation of switch status. A stainless-steel-plated metal body and included gasket help provide an IP69K waterproof rating.

The switch is rated for 20A on 12-24VDC systems and has a mechanical life of 50,000 cycles plus an electrical life of 10,000 cycles. A 4-foot lead is included. Installation requires a 22mm mounting hole in material up to 6mm thick, with color-coded contacts simplifying wiring. Have a look at the rest of our marine electrical switches.
