Bluewater 22mm Nav/Anchor Push Button Switch, 1-Ft Lead

Bluewater 22mm Nav/Anchor Push Button Switch, 1-Ft Lead

Original price was: $56.00.Current price is: $44.60.

Category:

Description

The Bluewater 22mm Nav/Anchor Push Button Switch provides dedicated navigation and anchor-light control in a compact stainless-steel marine switch. It combines two lighting functions in one round control while helping maintain a clean, modern helm layout.

The LED ring uses blue illumination when off, green for the first ON position, and red for the second ON position, allowing operators to identify status quickly. The stainless-steel-plated body and included gasket help provide an IP69K waterproof rating.

The switch is rated for 20A on 12-24VDC systems, with a mechanical life of 50,000 cycles and an electrical life of 10,000 cycles. A 1-foot lead is included. Installation requires a 22mm hole in material up to 6mm thick, followed by connection of the color-coded switch and LED contacts. Have a look at the rest of our marine electrical switches.
