Blue Sea 8385 DC 8 Position Horizontal Panel

Description

The Blue Sea Systems 8385 is an 8 position DC panel in horizontal layout, running 12 or 24 volts at up to 100A. Eight circuits is enough for a small cruiser or a well-equipped runabout, and the horizontal shape drops into shallow console space.

All positive, negative and grounding buses are installed and the panel ships pre-wired. Label positions come backlit as standard with no kit required, and ON indicating LEDs sit in every circuit position. Metered versions include a toggle switch covering up to three battery banks, and analog meters can be upgraded to 24 volts later using the 8240 or 8243 units.

The body is heavy 1/8 inch 5052 aluminum under a two-part polyurethane slate gray finish, with MIL-C-5541C or equivalent immersion undercoating beneath it. Countersunk mounting holes, industry standard height and width, a cutout template, detailed instructions and 30 common large format labels are all part of the package, with over 500 individual labels available. Browse our marine electrical panels.
