Blue Sea 8096 DC 6 Position Toggle Breaker Panel

Sale!
Blue Sea 8096 DC 6 Position Toggle Breaker Panel

Blue Sea 8096 DC 6 Position Toggle Breaker Panel

Original price was: $235.16.Current price is: $187.88.

Category:

Description

The Blue Sea Systems 8096 is a 6 position DC panel using white toggle branch breakers, laid out long and low at 10.5 inches wide by 3.75 tall and only 2.5 inches deep. That shallow depth is worth noting if the panel is going into a console or a locker face with structure close behind it.

Six 7210 A-Series white toggle single pole 15A breakers come installed. Nominal voltage is 12 or 24 volts and maximum amperage is 100A per bus. Positive, negative and grounding buses are installed with the panel fully pre-wired, label positions are backlit as standard, and ON indicating LEDs are fitted in every position.

Metered versions carry a toggle switch that reads across up to three battery banks, and panels supplied with analog meters can be moved to 24 volts by the owner using the 8240 or 8243 units. The 8030 basic DC panel label set with 30 labels is included. Browse more marine electrical panels.
