Blue Sea 8076 AC Main +11 Position Toggle Breaker Panel

Description

The Blue Sea Systems 8076 is an AC panel with a main plus 11 branch positions in white toggle format. Once a boat has a charger, a water heater, a couple of outlet circuits and air conditioning, the AC side needs proper protection of its own rather than breakers borrowed from wherever there was room.

It comes populated. Eight 7210 A-Series white toggle single pole 15A branch breakers, one 7238 A-Series double pole 30A main. An 8244 AC micro voltmeter reads 0 to 150 volts and an 8246 AC micro ammeter reads 0 to 50 amps through its coil, so incoming shore voltage and actual draw are both on the face. Twelve green 120V AC LEDs and one red 120V AC LED are installed.

The red one is reverse polarity, and it pays for itself the first time you plug into a miswired pedestal. Hot, neutral and safety ground buses are installed and the panel arrives fully pre-wired. Circuit label positions are backlit as standard, no kit required, with ON indicating LEDs throughout. Nominal voltage is 120V AC and the panel is 10.5 inches wide by 7.5 tall. A set of 30 basic AC panel labels is included. More in our marine electrical panels.
