Blue Sea 4307 WeatherDeck 12V DC Waterproof Switch Panel – 6 Position | 4307

Sale!
Blue Sea 4307 WeatherDeck 12V DC Waterproof Switch Panel - 6 Position | 4307

Blue Sea 4307 WeatherDeck 12V DC Waterproof Switch Panel – 6 Position | 4307

Original price was: $64.85.Current price is: $37.35.

SKU: 51815 Categories: ,

Description

WeatherDeck® 12V DC Waterproof Switch Panel – 6 Position

  • Integrated switch guards reduce the risk of accidental switching
  • Panels can be mounted in four different orientations
  • Panel front rated IP67 when properly mounted with watertight mounting gasket
  • UV stabilized weather-resistant faceplate snaps on and off providing access to components and concealing mouting screws

Weatherproof:Waterproof
Positions:6
Nominal Voltage:12V DC/24V DC
Circuit Protection:None
Maximum Amperage:15A @ 12V DC (per circuit)
Panel Cumulative Rating: 45A
Material:Reinforced Polycarbonate
Height:6.00″(152.4 mm)
Width:3.88″(98.55 mm)
Depth:2.50″(63.5 mm)
Weight:1.15lb (0.52 kg)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Download Owner’s Manual (PDF)
