Blue Sea 3113 SMS Panel Enclosure – 6 Blank Circuits

Description

The Blue Sea Systems 3113 is an SMS panel enclosure supplied with six blank circuit positions and no breakers fitted, for installations where you are specifying the protection yourself. It is built for main circuit breakers and other large frame devices, and meets ABYC E-11 when an ELCI main goes in it and the box is mounted within 10 feet of the AC shore power inlet.

Six blanks is the most open configuration in the SMS range. Positions take Carling Technologies A and C Series flat rocker breakers and ELCI mains, so the enclosure can be loaded for shore power protection, branch distribution, or a mix of the two.

The mounting box is glass filled polycarbonate with a clear cover that overlaps the base for strength and better gasket coverage, sealing against an oversized polyurethane gasket formed in place. The stainless hinge pin lifts out for unobstructed installation and the stainless latch closes the cover without a fastener penetrating the enclosure. The enclosure measures 6 by 6 by 4 inches, 7.6 by 7.4 by 4.7 inches overall. Mounting hardware and the instruction manual are included. See our other marine electrical panels.
