Blue Sea 1190 ELCI Main 30A Panel – 1 Position

Description

The Blue Sea Systems 1190 combines a 30A double pole ELCI main with one 15A branch position, which makes it the smallest complete AC panel Blue Sea builds rather than just a main breaker in a box. It measures 4.75 inches high by 4.88 wide by 3.99 deep and weighs a pound.

The main is a residual current breaker tripping at 30 mA of leakage, covering the boat for overcurrent and leakage to ABYC E-11. A 7403 A-Series flat rocker single pole 15A breaker handles the branch circuit, and the ELCI itself is the 3102100 A-Series double pole 120V AC unit. A red reverse polarity LED sits on the face.

Label backlighting uses green LEDs, which is worth understanding before you fit it. The labels light whenever the panel is powered, no matter what position the individual switches are in, so backlighting tells you the panel is live and the ON indicators tell you which circuits are running. The 4206 AC basic square format label set is included. Nominal voltage is 120V AC. Browse more marine electrical panels.
