The BXW2003 includes the underslung coupler hitch head, 2.5″ shank with a 9 Hole/9″ receiver stinger, clamp-on brackets, and spring bars rated for 2000 lbs. tongue weight, for trailers with underslung couplers.
Evenly distributes weight over axles of tow vehicle and trailer for stability and control
Creates a level ride for both tow vehicle and trailer
Built-in sway control helps to prevent trailer sway
Constant tension in trunnions helps force trailer in line
Rotating lift brackets ensure that chains are tight and secure to keep spring bars from moving
Trunnion spring bars flex for a controlled, even ride
Easily lock in place and remove with included pin and clip
Interchangeable with other SwayPro spring bars (sold separately) to raise or lower the weight capacity
2 Grease zerks inside head assembly make maintenance simple and clean
Unique, rotating-latch lift brackets connect spring bars to trailer
Quick and simple to use – insert lift chain into slot and rotate bracket with wrench
Clamp-on design – no drilling needed
Required tilt is built into head assembly – no adjustment needed
Powder coated steel construction
System includes head assembly, adjustable shank, spring bars, lift chains, rotating lift brackets with handles, reducer bushing for ball shank, pin and clip, 2-5/16″ hitch ball, and all necessary hardware
Tongue weight: 1,500 lbs – 2,000 lbs
Gross towing weight: 20,000 lbs
Application:
2-1/2″ x 2-1/2″ Trailer hitch receivers rated for use with weight distribution systems
Trailers with frame height between 3″ and 6″
Ball size: 2-5/16″
Lift-bracket positioning: mount about 29″ back from hitch ball
Designed for use on trailers with bottom-mounted couplers
Maximum rise: 8″
Maximum drop: 2″
Overall height: 12-1/2″
Distance between front of shank and back of receiver: 13″
Distance between front of shank and center of hitch pin hole: 10″
Distance between back of shank and center of hitch pin hole: 8″
Adjustment holes are spaced 1-1/4″ apart on center
