Bennett ES2000 Euro Style Rocker Switch

Description

Bennett ES2000 Euro Style Rocker Switch

The Bennett ES2000 Euro Style Rocker Switch is a premium trim tab control designed for Bennett hydraulic trim tab systems, delivering smooth and precise adjustment right from your helm. Featuring an ergonomic Euro-style design and water-resistant construction, this switch offers reliable performance in demanding marine environments.

Built for simplicity and durability, the Bennett ES2000 provides positive “click” action that lets you fine-tune your boat’s trim tabs with confidence, improving handling, planing performance, and ride quality. A lock-out feature prevents pressing both directions at once, ensuring safe and intuitive operation.

The control easily installs into a standard 2-1/2″ switch cutout, making it a perfect replacement or upgrade for original trim tab switches. Suited for a wide range of vessels equipped with Bennett hydraulic systems, the ES2000 adds both functionality and style to your helm station.

Key Performance Features

• Positive Click Feedback: Unlike soft-touch pads, these rockers provide a distinct mechanical “click,” allowing you to feel exactly when the pump engages.

• Ergonomic Euro Design: Features a curved, attractive profile that matches modern helm aesthetics and is easy to operate even while wearing gloves.

• Water-Resistant Construction: Built specifically for the marine environment to withstand spray and high-humidity conditions.

• Standard 2-1/2″ Cutout: Designed to fit into the same mounting hole as older Bennett rocker switches, making it an ideal “drop-in” upgrade for older boats.

• Simplified Wiring: Uses a straightforward 4-wire color-coded system to control the Port and Starboard actuators.

Technical Specifications

Wiring Guide (Color Codes)

The ES2000 uses the standard Bennett hydraulic wiring convention:

• Orange (with Fuse): 12V Positive (+) Power

• Blue: Pump Pressure (Trim Tabs Down / Bow Down)

• Yellow: Pump Retract (Trim Tabs Up / Bow Up)

• Red: Port Valve

• Green: Starboard Valve

In The Box

• 1 x ES2000 Rocker Switch Control

• 1 x Snap-on Bezel

• 4 x Mounting Screws (8)

• Ring Terminals (for wire attachment)

• Installation Instructions

Pro Tip: When installing, use a 2-1/2″ hole saw for the center cutout. To avoid cracking the gelcoat, run the hole saw in reverse until you are through the top layer of fiberglass, then switch to forward.
